AirWorks AWK-1131A Web Console Configuration
3-14
Security mode
Setting Description Factory Default
Open No authentication Open
WEP Static WEP is used
WPA WPA is used
WPA2 Fully supports IEEE 802.11i with “TKIP/AES + 802.1X”
Open
For security reasons, you should NOT set security mode to Open System, since authentication and data
encryption are NOT performed in Open System mode.
WEP (only for legacy mode)
NOTE
Moxa includes
WEP security mode only for legacy purposes. WEP is highly insecure and is considered fully
deprecated by the Wi
-Fi alliance. We do not recommend the use of WEP security under any circumstances.
According to the IEEE
802.11
standard, WEP can be used for
authentication and data encryption
to maintain
confidentiality. Shared
(or Shared
Key) authentication
type
is used if WEP
authentication and
data encryption
are both needed.
Normally,
Open (or Open System)
authentication
type is used when
WEP data encryption is
run with
authentication
.
When WEP is enab
led as a security
mode, the length of a key
(so-
called
WEP seed
) can be specified in
64/128 bits, which is actually a 40/104-bit secret key with a 24-bit initialization vector. The AWK-1131A
provides 4 entities of WEP key settings that can be selected to use with Key index. The selected key setting
specifies the key to be used as a send-key for encrypting traffic from the AP side to the wireless client side.
All 4 WEP keys are used as receive-keys to decrypt traffic from the wireless client side to the AP side.
The WEP key can be presented in two Key types, HEX and ASCII. Each ASCII character has 8 bits, so a
40-bit (or 64-bit) WEP key contains 5 characters, and a 104-bit (or 128-bit) key has 13 characters. In hex,
each character uses 4 bits, so a 40-bit key has 10 hex characters, and a 128-bit key has 26 characters.
Authentication type
Setting Description Factory Default
Open Data encryption is enabled, but without authentication Open
Shared Data encryption and authentication are both enabled.
Key type
Setting Description Factory Default
HEX Specifies WEP keys in hex-decimal number form HEX
ASCII Specifies WEP keys in ASCII form
Key length
Setting Description Factory Default
64 bits Uses 40-bit secret keys with 24-bit initialization vector 64 bits
128 bits Uses 104-bit secret key with 24-bit initialization vector
