- 10 -
LED
Color
State
Description
TP Port LED Indicators (Port Interface)
100M Green
On
TP port’s 100Mbps link is active
Blinking
Data is being transmitted at 100 Mbps
Off
TP port’s 100Mbps link is inactive.
10M Amber
On
TP port’s 10Mbps link is active.
Blinking
Data is being transmitted at 10 Mbps
Off
TP port’s 10Mbps link is inactive.
Specifications
WLAN Interface
Standards
IEEE 802.11i for Wireless Security
IEEE 802.3u 10/100BaseT(X) for Ethernet LAN
IEEE 802.3af for Power-over-Ethernet
Security
WPA /WPA2 (IEEE 802.1X/ RADIUS, TKIP and
AES)
Connection
10-pin removable terminal block
Alarm Contact
1 relay output (1 A @ 24 VDC)
Digital Input 2 electrically-isolated inputs
+3 to -30 V for state “0” (OFF)
+13 to +30 V for state “1” (ON)
Max. input current: 8 mA
Console
RS-232 (RJ45 type)
LAN Port
10/100BaseT(X) auto negotiation speed
LED Indicators
PWR1, PWR2, PoE, FAULT, STATE
Power Requirements
Input Voltage
12 to 48 VDC, redundant dual DC power inputs or
48 VDC Power-over-Ethernet (IEEE 802.3af)
Connector
10-pin removable terminal block
Reverse Polarity
Protection
Present
Physical Characteristics
Housing
Aluminum, providing IP30 protection
Dimensions
53.6 x 135 x 105 mm (2.11 x 5.31 x 4.13 in)
Weight
700 g
Installation
DIN-Rail, wall mounting (with optional kit)
Environmental Limits
Operating Temperature
Standard models: 0 to 60°C (32 to 140°F)
Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Storage Temperature
-40 to 85ºC (-40 to 185ºF)
Ambient Relative
Humidity
5 to 95% (non-condensing)
Regulatory Approvals*
Safety
EN 60950-1, UL60950-1
EMC
FCC Part 15 Subpart B Class B, EN 55022/55024
*Please check Moxa’s website for the most up-to-date certification status.
WARRANTY
5 years
See http://www.moxa.com/warranty
