MultiMixer

™

10 is an extremely low noise, professional

quality, 10 channel stereo line mixer. The 6 panable inputs

(1 through 6) enable you to place a sound source any-

where in the stereo field. 2 of the 6 inputs (1 and 2) can

have their gain set for either line level or microphone use.

4 more channels (7, 8, 9 and 10) are unity gain inputs for

which there are no volume or pan controls. These channels

have to be controlled “at the source,” so they are ideal for

use as returns or AV ins. MultiMixer 10 comes with an

external 9 volt, 300 milliamp ac power adaptor. This adap-

tor should be plugged into a standard wall socket and

then into the MultiMixer’s back power jack. When this is

done the MultiMixer power LED will light. MultiMixer

will not work unless power is plugged in.

Multimedia Mixing. Many multimedia applications use

multiple sound sources. In a typical multimedia application

you might plug the MultiMixer in as follows: 1.) plug your

microphones into inputs 1 and 2 making sure that the gain

switches (on the side of the unit) are switched “up” to the

mic setting; 2.) connect the stereo output from your comput-

er soundcard to MultiMixer inputs 3 and 4; 3.) connect out-

puts from your MIDI tone module to inputs 5 and 6; and 4.)

connect the stereo audio output from a CD-ROM to unity

gain stereo input 9/10. Now, you can use the MultiMixer

pan pots to position the sounds of channels 1 through 6

wherever you want them.
