• Top – Signal Level LED. Shows when any audio signal

is coming into the MultiMixer.

• Top – Clip LED. Shows when the internal main ampli-

fiers inside of the MultiMixer are clipping. It is accept-

able to see these LEDs light occasionally, but if they are

solidly lit you should find the individual signal that is

too hot and turn it down.

• Back – Inputs 1 and 2. 1/4” mono phone jacks. These

two inputs may be set to either mic or line level using

the gain dip switches on the left side of the unit. Tip: if

you are using MultiMixer with an XLR microphone you

will have to get an XLR to 1/4” adaptor.

• Back – Inputs 3 through 6. RCA mono jacks. These are

line level mono inputs.

• Back – Inputs 7/8 and 9/10 (Stereo). 1/8” stereo mini-

jacks. These are line level unity gain stereo inputs. They

may be used as returns or AV/multimedia ins. Tip: since

the gain and balance of these inputs are fixed you must be

able to control these signals at their source.

•Back – Main Outputs (L, R). RCA jacks. These are the

main MultiMixer left and right line level outputs. They

should go to either a power amplifier or powered speak-

er inputs.

• Back – Main Output (Stereo). 1/8” stereo jack. Same

as the Main L and R outputs above except on stereo jack.

• Back – 9v ac power. The jack into which you plug a 9v

300 milliamp ac power adapter. Important: MultiMixer

will not work unless it receives power at this jack.

• Side – Gain Dip Switches. These two dip switches

independently control the gain of channels 1 and 2. In

the up position the gain is set for microphones and in

the down position for line level signals.
