1. Introduction
The Moxa UPort 1200/1400/1600 are advanced USB-to-serial converters that add 2, 4, 8, or 16 serial ports to
a PC through the PC’s USB port. The UPort 1200/1400/1600 are compatible with both new and legacy RS-232
or RS-422/485 devices. These plug-and-play USB-to-serial converters are ideal for mobile, instrumentation,
and point-of sale applications.
In this manual, we refer to the products in the series collectively as the UPort 1200/1400/1600 Series, or
simply as the UPort. The UPort 1200/1400/1600 Series includes the following models:
UPort 1250 2-port RS-232/422/485 USB-to-serial converter
UPort 1250I 2-port RS-232/422/485 USB-to-serial converter w/ isolation protection
UPort 1410 4-port RS-232 USB-to-serial converter
UPort 1450 4-port RS-232/422/485 USB-to-serial converter
UPort 1450I 4-port RS-232/422/485 USB-to-serial converter w/ isolation protection
UPort 1610-8 8-port RS-232 USB-to-serial converter
UPort 1650-8 8-port RS-232/422/485 USB-to-serial converter
UPort 1610-16 16-port RS-232 USB-to-serial converter
UPort 1650-16 16-port RS-232/422/485 USB-to-serial converter
The following topics are covered in this chapter:
Overview
ADDC
TM
(Automatic Data Direction Control) for RS-485
ARDC (Automatic Recovery Data Communication)
Ordering Information
Product Features
Product Specifications
Panel Layout
UPort 1250
UPort 1250I
UPort 1410/1450/1450I
UPort 1610-8/1650-8
UPort 1610-16/1650-16
Dimensions
UPort 1250
UPort 1250I
UPort 1410/1450/1450I
UPort 1610-8/1650-8
UPort 1610-16/1650-16
