Braun TS525A TexStyle 5 [10/80] G cleaning the anticalc valve

• Keep the iron in the upright position and

connect it to the mains. Select the tem-

perature according to the ironing guide on

the heel rest of the iron or on the label in

your garments.

• The temperature pilot light (7) goes off,

when the desired temperature is reached

(after approx. 1 minute).

C Ironing

1 Steam on/off

For steam ironing the temperature selector

(6) must be set according to drawing C1

from greater than «••» to «max».

Press the steam button (3) to start the

steam mode.

steam on

steam off

With the steam button in its upper position

(steam on), turn the steam regulator (3a)

to adjust the steam quantity.

We recommend a medium steam setting

for all normal ironing. Only when ironing

linen, thick cotton or similar fabrics we

recommend the maximum steam setting.

Preconditioning

Steam develops also horizontally at the

front area of the sole plate. This precondi-

tions the textiles by «pre-steaming», thus

making ironing easier.

Be careful – steam comes out laterally.

2 Power shot

Prior to use, press the power shot button

(5) 3 to 4 times to activate it. Press the

power shot button in intervals of at least

5 seconds.

Power shot can be activated when dry

ironing. However, the temperature selector

has to be set in the range between «•••»

to «max». The power shot function can

also be used in the vertical position for

steaming hanging clothes.

3 Spray function

Press the spray button (4).

4 Dry ironing

Turn the steam mode off by pressing the

steam button (3) so that it catches in the

lower position.

Automatic shut-off

(model TS 525 A only)

The auto-off mechanism causes a slight

rattling noise during ironing. This is normal

and in no case indicates a fault of the iron.

The

«auto-off» light

(8) will ﬂ ash when the

automatic shut-off is activated.

This happens when the iron has rested …

– horizontally on its sole plate for about

30 seconds or

– vertically on its heel rest for about

8 minutes.

To turn on the iron again, just move it.

When the temperature pilot light stops

ﬂ ashing, the electrical power is on again.

The automatic shut-off will be activated

approximately 2 minutes after the iron is

plugged into a socket.

D Textile Protector

(model TS

535 TP, TS

545 TP S only)

The Braun Textile Protector protects

delicate fabrics from heat damage and

makes it possible to iron most dark fabrics

without an intermediate cloth. To check

the reaction of your fabrics before you

start ironing, we recommend that you iron

a small section of material on the reverse

side. With the Protector, you are able to

iron delicate fabrics with the temperature

setting «•••» to «max», so that you can

use all steam functions your iron offers.

After having attached the Textile Protector,

wait about 1 ½ minutes before you start

ironing.

E After ironing

• Unplug the iron and press the steam on/off

button (3) so that it catches in its lower

position (steam off).

• To prolong the life of the iron, empty the

water tank.

• Store the cool iron in a dry place always

standing on its heel rest.

F Maintenance and cleaning

To clean the sole plate, use steel wool.

Then wipe the sole plate clean with a cloth.

Never use a scouring pad, vinegar nor

other chemicals. To clean the soft material

of handle and power shot and spray

buttons, use soapy water.

G Cleaning the anticalc valve

The iron’s anticalc valve is located at the

lower end of the steam button (3). It has

to be decalciﬁ ed regularly (e.g. when the

steam development is insufﬁ cient).

Proceed as follows:

1) Unplug the iron and empty the water tank.

2) Press the steam button so it is lifted.

3) Remove carefully (some water may now

leak from the sole plate).

4) Do not touch the anticalc valve.

5) Immerse in vinegar (not vinegar essence)

or lemon juice until the lime becomes soft.

5712710034_TS_545-505_S06-80.indd 105712710034_TS_545-505_S06-80.indd 10 03.06.13 10:4203.06.13 10:42
