Moxa DA-710-LX [3/3] Ordering information

3

Power Computers

© Moxa Inc. All Rights Reserved. Updated May. 21, 2014. Specifications subject to change without notice. Please visit our website for the most up-to-date product information.

Software Specifications

Linux

OS: Linux 2.6.26, Debian 5 (Lenny)

File System: EXT2

Internet Protocol Suite: TCP, UDP, IPv4, SNMP v1/v2c/v3, ICMP,

ARP, HTTP, CHAP, PAP, SSH 1.0/2.0, SSL, DHCP, NTP, NFS, Telnet,

Dial-up Networking: PPP Daemon for Linux allows Unix machines to

connect to the Internet through dialup lines, using the PPP protocol, as

a PPP server or client. Works with ‘chat’, ‘dip’, and ‘diald’, among

(many) others. Supports IP, TCP, UDP and (for Linux) IPX (Novell).

File Server: Enables remote clients to access files and other resources

over the network

Watchdog: Features a software function to trigger system reset in a

user specified time interval (Moxa API provided)

Application Development Software:

• Moxa API Library

SMTP, SNMPv2, TCP, UDP, IPv4, ICMP, IGMP, IPsec, TAPI, ICS, PPP,

CHAP, EAP, PPPoE, PPTP, NetBIOS

Web Server (IIS): Allows users to create and manage websites

Silverlight 2.0: A free runtime that powers rich application experiences

and delivers high quality, interactive video across multiple platforms

and browsers, using the .NET framework

Remote Desktop: The Terminal Server Remote Desktop component

provides remote access for the desktop of a computer running

Terminal Services

Remote Registry Service: Enables remote users to modify registry

• Moxa API Library

• Microsoft .Net Framework 3.5 with SP1

• Active Directory Service Interface (ADSI) Core

• Common Control Libraries

• Common File Dialogs

• Direct3D, DirectPlay, DirectShow, and Direct show lters

• Mapi32 Libraries

• Message Queuing (MSMQ) Core

• Microsoft Visual C++ Run Time Libraries

• Power Management dynamic-link library

• Without ears: 400 x 420 x 180 mm (15.75 x 16.54 x 7.09 in)

• With ears: 400 x 480 x 180 mm (15.75 x 18.90 x 7.09 in)

Mounting: Standard 19-inch rackmount

Environmental Limits

Operating Temperature: -10 to 50°C (14 to 122°F)

Storage Temperature: -20 to 80°C (4 to 176°F)

Ambient Relative Humidity: 5 to 95% (non-condensing)

Power Requirements

Input Voltage: Single or dual inputs, 100 to 240 VAC/VDC auto-

ranging, 47 to 63 Hz, terminal block

Part 15 Subpart B Class A

Green Product: RoHS, CRoHS, WEEE

Alert Tools: Built-in buzzer and RTC (real-time clock) with backup

lithium battery

Automatic Reboot Trigger: Built-in WDT (watchdog timer) supporting

1-255 time interval levels for system reset, software programmable

Warranty

Warranty Period: 3 years

expansion slots, 4 DIs, 4 DOs, VGA, CompactFlash, USB, Windows Embedded Standard 2009

DA-710-LX: x86-based rackmount embedded computer with 2 RS-232 ports, 4 LANs, 4 peripheral

expansion slots, 4 DIs, 4 DOs, VGA, CompactFlash, USB, Linux 2.6

Expansion Modules (can be purchased separately)

DA-SP08-I-DB: 8-port RS-232/422/485 serial module with DB9 connector and digital isolation

DA-SP08-DB: 8-port RS-232/422/485 serial module with DB9 connector

DA-SP08-I-TB: 8-port RS-232/422/485 serial module with terminal block connector and digital

isolation

DA-SP38-I-TB: 8-port RS-422/485 serial module with terminal block connector and digital isolation

DA-SW08-RJ: 8-port 10/100 Mbps unmanaged switch module

• Ethernet cable: RJ45 to RJ45 cross-over

• Documentation and software CD or DVD

• Quick installation guide (printed)

• Warranty card
