Moxa DA-662A-I-8-LX [25/63] Enabling and disabling daemons
![Moxa DA-662A-I-8-LX [25/63] Enabling and disabling daemons](/views2/1199608/page25/bg19.png)
DA-662A Series Software Managing Embedded Linux
3-4
MTD device [/dev/mtd0] erase 128 Kibyte @ 60000 -- 100% complete.
Wait to write file ...
Completed 100%
Now upgrade the file [kernel].
Format MTD device [/dev/mtd1] ...
MTD device [/dev/mtd1] erase 128 Kibyte @ 1a0000 -- 100% complete.
Wait to write file ...
Completed 100%
Now upgrade the file [root-file-system].
Format MTD device [/dev/mtd2] ...
MTD device [/dev/mtd2] erase 128 Kibyte @ e00000 -- 100% complete.
Wait to write file ...
Completed 100%
Now upgrade the file [directory].
Format MTD device [/dev/mtd5] ...
MTD device [/dev/mtd5] erase 128 Kibyte @ 20000 -- 100% complete.
Wait to write file ...
Completed 100% Now upgrade the new configuration file.
Upgrade the firmware is OK. Rebooting
Loading Factory Defaults
To load the system‘s factory default settings, press the reset button for at least 5 seconds. Doing so will destroy
all of the files in the /home and /etc directories. While holding the button for the first 5 seconds, the ready
LED will blink once each second. After holding the button continuously for more than 5 seconds, the ready LED
will switch off, indicating that the factory defaults have been loaded.
Enabling and Disabling Daemons
The following daemons are enabled when the DA-662A series boots up for the first time.
snmpd SNMP Agent daemon
telnetd Telnet Server / Client daemon
inetd Internet Daemons
ftpd FTP Server / Client daemon
sshd Secure Shell Server daemon
httpd Apache WWW Server daemon
Type the command ps to list all processes currently running.
192.168.3.127 - PuTTY
root@Moxa:~# cd /etc
root@Moxa:~# ps
PID USER VSZ STAT COMMAND
1 root 1632 S init [3]
2 root 0 SW [kthreadd]
3 root 0 SW [ksoftirqd/0]
5 root 0 SW [kworker/u:0]
6 root 0 SW [rcu_kthread]
7 root 0 SW< [khelper]
155 root 0 SW [sync_supers]
157 root 0 SW [bdi-default]
158 root 0 SW< [kintegrityd]
160 root 0 SW< [kblockd]
