DA-662A Series Software Managing Communications

4-15

29: system.9.1.4.4 (timeticks) 0 days 00h:00m:00s.09th (9)

30: system.9.1.4.5 (timeticks) 0 days 00h:00m:00s.09th (9)

31: system.9.1.4.6 (timeticks) 0 days 00h:00m:00s.19th (19)

32: system.9.1.4.7 (timeticks) 0 days 00h:00m:00s.22th (22)

33: system.9.1.4.8 (timeticks) 0 days 00h:00m:00s.22th (22)

34: system.9.1.4.9 (timeticks) 0 days 00h:00m:00s.22th (22)

***** SNMP QUERY FINISHED *****

NOTE

Click on the following links for more information about MIB II and RS-232 like groups:

http://www.faqs.org/rfcs/rfc1213.html

http://www.faqs.org/rfcs/rfc1317.html

The DA-662A series does NOT support SNMP trap.
