DA-662A Series Hardware Hardware Introduction

2-5

LCD Screen

The DA-662A series has an LCD screen on the front panel. The LCD screen can display 16 columns and 2 rows

of text. After the DA-662A series boots up, the LCD screen will display the model name and firmware version:

D A - 6 6 2 A - 1 6

V E R . 1 . 0

Push Buttons

There are four push buttons on the DA-662A series’ front panel. The buttons are used to enter text onto the

LCD screen. The buttons are MENU, (up cursor), (down cursor), and SEL:

Button Action

MENU Displays the main menu.

Scrolls up through a list of items shown on the LCD screen’s second line.

Scrolls down through a list of items shown on the LCD screen’s second line.

SEL Selects the option listed on the LCD screen.

Real-time Clock

The DA-662A series’ real time clock is powered by a lithium battery. We strongly recommend that you do not

replace the lithium battery without help from a qualified Moxa support engineer. If you need to change the

battery, contact the Moxa RMA service team.

WARNING

There is a risk of explosion if the battery is replaced by an incorrect

type.
