DA-662A Series Hardware Hardware Connection Description

3-2

Placement Options

Rack Mounting

The DA-662A series is designed to be mounted on a standard 19-inch rack. Two L-shaped metal plates are

included as standard accessories with the DA-662A series. Use the enclosed pair of L-shaped metal plates and

screws to fasten your DA-662A series to the rack cabinet. Two placement options are available. You can either

lock the front or the rear panel of the DA-662A series to the front of the rack. Each L-shaped plate has 6 holes,

leaving two outer or inner holes open for your convenience.

Connecting the Hardware

This section describes how to connect the DA-662A series to serial devices. The topics covered in this section

are: Wiring Requirements, Connecting the Power, Connecting to the Network, Connecting to a

Serial Device, and Connecting to the Console Port.

Wiring Requirements

ATTENTION

Safety First!

Be sure to disconnect the power cord before instal

ling and/or wiring your DA-662A series.

Wiring Caution

Calculate the maximum possible current in each power wire and common wire.

Observe all electrical codes

dictating the maximum current allowable for each wire size.

If the current goes above the maximum ratings, the wiring could overheat, causing serious damage to your

equipment.

Temperature Caution

Be careful when handling

the DA-662A series. When plugged in, the DA-662A series’ internal components

generate heat, and consequently the outer casing may feel hot to the touch.

You should observe the following common wiring rules:

• Use separate paths to route wiring for power and devices. If power wiring and device wiring paths must

cross, make sure the wires are perpendicular at the intersection point.

NOTE: Do not run signal or communication wiring and power wiring in the same wire conduit. To avoid

interference, wires with different signal characteristics should be routed separately.

• You can use the type of signal transmitted through a wire to determine which wires should be kept separate.

The rule of thumb is that wiring that shares similar electrical characteristics can be bundled together.

• Keep input wiring and output wiring separate.

• Where necessary, it is strongly advised that you label wiring to all devices in the system.

Connecting the Power

To power on the DA-662A series, use a power cord to connect the power line to the DA-662A series’ AC power

connector. The power connector is located on the right side of the rear panel. Next, turn on the power switch.

The DA-662A series takes about 30 seconds to boot up. Once the device is ready, the Ready LED on the front

panel will light up, and the DA-662A series model name and firmware version will appear on the LCD screen.
