UC-8410A Series Linux Software Advanced Configuration of Peripherals

3-2

Serial Ports

The serial ports support RS-232, RS-422, and RS-485 2-wire operation modes with flexible baudrate settings.

The default operation mode is set to RS-422. Use the

setinterface command to change the operation

mode as follows:

Usage: setinterface device-node [interface-no]

Device-node: /dev/ttySn; n = 0,1,2,...

Interface-no: Refer to the following table

Interface

Number

Operation Mode

None Display current setting

0 RS-232

1 RS-485 2-wire

2 RS-422

3 RS-485 4-wire

For example, to set /dev/ttyS0 to RS-485 2-wire (RS485-2W) mode, use the following command:

moxa@Moxa:~# sudo setinterface /dev/ttyS0 1

Now setting is RS485-2W mode

moxa@Moxa:~# sudo setinterface /dev/ttyS0

UART Port#0 is in RS485-2W Mode

stty

The stty command is used to manipulate the serial terminal settings. You can view and modify the serial

terminal settings with this command as described below:

Displaying All Serial Terminal Settings

The following text shows how to display all settings:

moxa@Moxa:~$ sudo stty -a -F /dev/ttyS0

speed 9600 baud; rows 0; columns 0; line = 0;

intr = ^C; quit = ^\; erase = ^?; kill = ^U; eof = ^D; eol = <undef>;

eol2 = <undef>; swtch = <undef>; start = ^Q; stop = ^S; susp = ^Z; rprnt = ^R;

werase = ^W; lnext = ^V; flush = ^O; min = 1; time = 0;

-parenb -parodd cs8 hupcl -cstopb cread clocal -crtscts

-ignbrk -brkint -ignpar -parmrk -inpck -istrip -inlcr -igncr icrnl ixon -ixoff

-iuclc -ixany -imaxbel -iutf8

opost -olcuc -ocrnl onlcr -onocr -onlret -ofill -ofdel nl0 cr0 tab0 bs0 vt0 ff0

isig icanon iexten echo echoe echok -echonl -noflsh -xcase -tostop -echoprt

echoctl echoke
