UC-8410A Hardware Appearance and Dimensions
2-4
LED Name Status Function
Diagnostic Green/Yellow/
Red
Various combinations of the on/off/blinking statuses of the
Green/Yellow/Red LEDs indicate different hardware
diagnostic
statuses. Refer to the Diagnostic LEDs section for details.
Diagnostic LEDs
The descriptions of the statuses indicated by the diagnostic LEDs are listed in the table below:
Priority
Green Yellow Red Status Description
1 On Off Blinking Self-diagnosis in progress
2 Off Off On LAN1 Ethernet controller error
3 Blinking Off On LAN2 Ethernet controller error
4 On Off On LAN3 Ethernet controller error
5 Off On On UART interface error—i
ndicates an error in any one of the UART
interfaces
6 Blinking Blinking Blinking LED device issue
7 Off Blinking On Button device issue
8 On Blinking Blinking Ready for reset to factory default
9 Off On Blinking CPU usage (over 90%)
10 Off On Off RAM usage (over 90%)
11 Blinking On Off Disk usage (over 90%)
12 Blinking On Blinking File system corrupted
13 Blinking Blinking On TPM device issue
Reset Button
The Reset button returns the UC-8410A to its factory default configuration and also performs the system
diagnostic function. Please check the table below for details:
Function Button Operation
Self-diagnosis The red LED will start blinking once you press the Reset button. Keep the button
pressed until the green LED lights up for the first time and then release the
button to enter the diagnostic mode. Refer to the Diagnostic LEDs section for
descriptions of the diagnostic statuses.
Resetting the computer to
the factory default
configuration
The red LED will start blinking once you press the Reset button. Keep the button
pressed until the green LED lights up for the second time and then release the
button to enter the process of resetting the computer to the factory default.
We recommend that you only use this function if the software is not working properly and you want to load the
factory default settings. To reset an embedded system, always use the software reboot command />reboot
to protect the integrity of data being transmitted or processed.
ATTENTION
Reset
button preserves user’s data
The
Reset button will NOT format the user directory and erase the user’s data. Pressing the Reset button
continuously for at least 5 seconds
will only load the configuration file. For the Linux OS, all files in the
/etc,
/home
, and /tmp directories will revert to their factory defaults, but other user data will still exist in the
Flash ROM.
For the Windows CE 6.0 OS, all registry configurations will revert to the factory default.
