V2616A Linux Software Configuration
2-2
Account Management
Connect the V2616A to a display and turn on the computer. Enter the following information to log in to the
computer:
Login: moxa
Password: moxa
For security reasons, we strongly suggest you disable the root account and change the password upon your
first login. After successfully logging in, the computer is configured to force you to first reset a new password:
login as: moxa
moxa@192.168.27.42's password:
You are required to change your password immediately (root enforced)
Linux Moxa 3.2.0-4-amd64 #1 SMP Debian 3.2.46-1 x86_64
#### #### ###### ####### ###### ##
### #### ### ### #### #### ###
### ### ### ### ### ## ###
### #### ## ## ### # ####
#### # ## ### ### ### ## ## ##
## ## # ## ### ## #### # ##
## ### ## ## ## ## #### # ###
## ## # ## ## ## ### #######
## ## # ## ### ### ##### # ##
## ### ## ### ### ## ### # ###
## ### ## ## ## ## ### ## ##
## ### ## ## ## # ### # ##
###### # ###### ######## ####### ########### ######
For further information check:
http://www.moxa.com/
Mount user file system.
moxa@Moxa:~#
To run commands as root, users shold not log in to the computer with the root account. Instead, users should
use the sudo command to run commands with root privileges. To do this, users must first be added to the sudo
group. Once a user is added to the sudo group, they may run commands requiring super-user privileges by
prefacing them with the sudo command. For example, to reconfigure the IP address of Ethernet port 1, a user
with sudo privileges will type sudo ifconfig eth0 192.168.100.100; the OS will then require the user to
enter his or her password before executing the command, as below:
moxa@Moxa:~# sudo ifconfig eth0 192.168.100.100
[sudo] password for moxa:
moxa@Moxa:~$ sudo ifconfig eth1
[sudo] password for moxa:
eth1 Link encap:Ethernet HWaddr 00:90:e8:00:df:fe
inet addr:192.168.100.100 Bcast:192.168.100.255 Mask:255.255.255.0
UP BROADCAST MULTICAST MTU:1500 Metric:1
RX packets:0 errors:0 dropped:0 overruns:0 frame:0
TX packets:0 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:1000
RX bytes:0 (0.0 B) TX bytes:0 (0.0 B)
Interrupt:41 Base address:0xe000
moxa@Moxa:~$
