Polaris PCWH 2061 Di [10/13] Function
![Polaris PCWH 2061 Di [10/13] Function](/views2/1020029/page10/bga.png)
• You should make the holes in the wall on
59 cm from each other horizontally and at
least on 2 m over the floor. This way the
heater should be at least on 1.8 m from the
floor level. See fig. 2, 5 and 6
• The depth of the holes in wall should be
42-45 mm, of 8 mm diameter. The tighten
screw should be protruded from the wall on
18-20 mm.
• You may use cord keeper inside the heater if the power cord is too long.
• After the heater installation, you should tighten the screws.
Appliance operation
Remote control
• Observing polarity, insert the batteries into the remote control.
• When pressing a button on the remote control, you will hear tones.
• When you will press the ON/OFF button, the “POLARIS” inscription will light on, the fan will be
turned on, the swing leafs will be opened, and the air stream will go inside the room. You will see the
inside temperature on the display.
• When you will press the "HEATER“ button on the RC, starts the first heating mode – 1kW (5
indicators light on for this mode from center to left and right sides). If you will press on the
"HEATER“ button one more time, you will turn on the second heating mode – 2kW (8 indicators light
on for this mode from center to left and right sides).
• Temperature setting. If you press the button, the temperature rises on 1 degree. The temperature
range is 18-45
0
С. If you already set the temperature on 45
0
С and press the button one more time. The
temperature will be set on 18
0
С.
• Setting of air flow swing. Press “Swing” button in order to turn this function on, press the button
one more time in order to turn in off.
• Air cleaning. If you will press the “ANION” button for one a time, the ionization function will be
activated. If you will press the button one more time, the function will be deactivated.
• Timer setting. Press the "TIMER" button on the RC in order to activate the timer. Each pressing on
the button increases timer time on 0.5 hour.
Attention! If you turn the heater off, the settings of timer will be deleted from the memory.
If the heater operates just in fan mode, the indicator of fan on the control panel lights out, all the
functions stop to operate.
The indicator of fan will light on, when the heater operates in heating mode. When you turn the heater
off, it will work in the fan mode for 30 seconds in order to cool the heating element. The indicator will
light on for this time.
The appliance operating with buttons on the body
Button
«function»
• Once you press the
«function»
button, you will hear the signal, the indicator will light on, the
fan will turn on, the swing leafs will open giving the air stream inside. The green indicator will light in
the center of the display. The air temperature will be shown on the display.
Fig 5
59cm
The distance between
the holes
Holes in wall
Wall
