TC-6110 / Windows 7 Installing Moxa Software

4-25

To use Synmap to set the power policy:

1. Start up MXview (or some other NMS) and open the MIB browser. For detailed instructions on loading

MXview, you may refer to

Loading the Synmap MIB File, steps 1 to 3.

2. In the MIB browser, navigate to

MOXA-SYS-MIB\VALUES\Moxa\embeddedComputer\MoxaSystem\powerMgmt\powerPolicy.

To change the Windows 7 power policy settings, highlight

the powerPolicy OID and click Set. This will open a dialog

called the Set Value dialog.

3. The Set Value dialog for the powerPolicy OID has two

variable fields: one showing the OID that is being called and

a second called Value, to indicate which power

management policy should be used. Use the integer 1 to

indicate the Balanced, 2 for the Power Saver, and 3 for

the High Performance policy. After entering the value,

close the dialog by clicking Set.

4. To check if the policy has been changed, navigate to the Windows 7 Control Panel, and open the Power

Options

tab, located under Control Panel  System Security.

ATTENTION

For more detailed information on the advanced settings of Windows 7 power management policies, you may

refer to Microsoft

’s online Windows support pages, which are currently (Jul. 2013) found at this link:

http://windows.microsoft.com/en

-us/windows7/change-create-or-delete-a-power-plan-scheme

Using Synmap to Read the Temperature Sensor

The following table shows the temperature sensor OIDs.

Item Name OID Access Description

tempSensorsIndex 1.3.6.1.4.1.8691.17.1.5.1.1.1.1 read-only Returns a list of numbers

(beginning with 1) that

corresponds with the available

T-sensors; these identifiers

are used by SNMP and for

system scripts.

tempSensorsDevice 1.3.6.1.4.1.8691.17.1.5.1.1.1.2 read-only Returns a list of string values

identifying the temperature
