V2406/2422/2426 Linux User’s Manual Software Configuration
2-5
Startup with Desktop Environment
In this section, we introduce the display configuration for the V2406/2422/2426 series. The V2406/2422/2426
series supports both VGA and DVI output. Connect the display to the V2406/2422/2426 computer and issue
the command
/etc/init.d/gdm start to start Xwindows from the text console. You can also start the
gnome desktop environment from the text console:
MOXA:~# /etc/init.d/gdm start
Or, issue the following command configure gnome-display-manager as a startup daemon:
MOXA:~# mv /etc/rc2.d/N30gdm /etc/rc2.d/S30gdm
You should see the following log in window:
