Alignment error

Out of sync

Out of range

Error Possible Reasons and Remarks

Output Error

The output error is related to the optical output of the LAGOON card. Only one

output error may appear. It is called Out of range. The out of range error may only

show up when you use ADAT Sync In or Optical In to determine the sample rate.

The audio channels were received in wrong order

(e.g. left and right channels interchanged). This error

should only appear temporarily when changing the

input data format (e.g. changing from

ADAT to

S/PDIF.)

Optical input and optical output do not have the same

sample rate, i. e. your external device is not

synchronized to the LAGOON (e.g. there is a CD-

Player connected to the optical input while your

LAGOON is the clock master). Select

Optical In as

Clock source in this case (General page).

1. You are using

S/PDIF as output signal and the sample

rate coming in from the optical input is less than 32

kHz or higher than 96 kHz.

2. You are using ADAT as output signal and the sample

rate coming in from the optical input is below 39 kHz

or above 51 kHz.

3. The LAGOON card does not receive a valid signal at

its optical input or at the ADAT Sync In. Check your

cabling and your connected external device.
