MPC-2240 Hardware Manual BIOS Setup
5-15
Step 2: Prepare the Upgrade File
You must use the BIOS upgrade installation file to upgrade the BIOS. Contact Moxa’s technical department for
assistance.
1. Get the BIOS upgrade installation file. The file name should have following format: 2240xxSx.exe (xx
refers to version numbers).
2. Copy the file to the Bootable USB Disk.
Step 3: Run the upgrade program on the MPC-2240 Series Panel Computer
1. Reboot the computer, press F2 while booting up to go to the Boot Manager
2. Select USB Disk as the first boot source. Press Enter to continue.
3. When boot up finishes, DOS screen will show up. Go to the directory where the upgrade file is located. For
example, if the upgrade file is stored in the MPC2240 folder, type cd MPC2240.
C:\cd MPC2240
4. Run the upgrade program by typing 22410S02.exe. Please note that the upgrade filename may vary
depending on the versions.
C:\MPC2240>22410S02.exe
5. The upgrade program will be automatically performed. Please wait until the procedure to be finished.
