Moxa MC-4510-C23 [3/3] Ordering information

Marine Displays and Computers

Ordering Information

Environmental Limits

Operating Temperature: -10 to 55°C (14 to 131°F)

Storage Temperature: -20 to 60°C (-4 to 140°F)

Ambient Relative Humidity: 5 to 95% (non-condensing)

Anti-vibration:

• 0.7 g, sine wave, 2-100 Hz, 1 Oct./min., 1.5 hr per axis

• 1 grms, random wave, 3-100 Hz, 2.5 hr per axis

• 2.1 g, sine wave, 2-50 Hz, 1 Oct./min., 1.5 hr per axis

Anti-shock: 50 g @ IEC 60068-2-27, half sine wave, 11 ms

Power Requirements

Input Voltage: 18 to 36 VDC (3-pin terminal block)

Power Consumption: 48.6 W

• 1.35 A @ 36 VDC

• 1.96 A @ 24 VDC

• 2.61 A @ 18 VDC

Available Models

MC-4510-C23: Industrial computer with Intel Core 2 Duo 2.26 GHz, 2 optically-isolated serial

ports, 2 Gigabit LANs, dual displays, CompactFlash, USB, audio

Standards and Certiﬁcations

Safety: UL 60950-1, IEC 60945 4th. IACS-E10, CCC (GB4943, GB9254,

GB17625.1)

EMC: EN 55022 Class B, EN 55024-4-2, EN 55024-4-3, EN 55024-4-4,

FCC Part 15 Subpart B Class B

Marine: IEC 60945 4th. IACS-E10

Green Product: RoHS, cRoHS, WEEE

Reliability

MTBF (mean time between failures): 175,865 hrs

Warranty

Warranty Period: 3 years

Details: See www.moxa.com/warranty

Package Checklist

• MC-4510-C23 embedded computer

• PS/2 to KB/MS Y-type cable

• 2 sets of hard disk drive cables

• Hard disk drive ground sticker

• Documentation and software CD

• Quick installation guide (printed)

• Warranty card
