www.moxa.com
info@moxa.com
Marine Displays and Computers
MPC-122-K Series
Introduction
Panel computers with Intel Core 2 Duo 2.26 GHz CPU, dual VGA/DVI
output, 2 Gigabit Ethernet ports, 2 serial ports, 7 USB 2.0 ports,
CompactFlash
The MPC-122-K panel computer features a 2.26 GHz Intel Core 2 Duo
processor with up to 4 GB of system memory to deliver a reliable, high
performance computing platform for industrial marine systems. Two
RS-232/422/485 optically-isolated serial ports and two gigabit Ethernet
LAN ports provide reliable serial communications alongside high
speed, redundant Ethernet LAN communications.
With it’s wide range of panel resolutions the MPC-122-K can be
adjusted to satisfy the display requirements for many different
marine applications, and also feature enhancements like wide viewing
angles, full range dimming, and optional optical bonding. Designed
as a modular unit, the MPC-1122-K can be conveniently and quickly
integrated into either new or existing systems, helping reduce overall
time-to-market and the associated deployment and integration costs.
MPC-122-K panel computers have proven resilience and reliability in
marine environments by meeting or surpassing the strict industrial
requirements defined in the IEC 60945, DNV, and IACS-E10 maritime
standards, and their IP66 rated enclosures provide significant
additional protection against the harsh effects of ocean elements.
Color-calibrated ECDIS models are also available upon request,
providing an ideal HMI alternative for ECDIS charting and navigation
stations.
Appearance
Computer
› 22’’ wide viewable image size with 16:10 aspect ratio and
1680 x 1050 pixel resolution
› High performance with Intel Core 2 Duo 2.26 GHz processor
› Full range dimming, optical bonding (optional), and wide angle
view (178˚ x 178˚)
› Dual independent displays (VGA + DVI-D)
› Water and dust proof IP66-rated enclosure (flush mounting)
› 2 Gigabits Ethernet LAN ports
› 2 RS-232/422/485 optically-isolated serial ports
› 7 USB 2.0 ports for high speed peripherals
› CompactFlash socket for storage expansion
› 2 SATA connectors for storage expansion
› Supports Windows 7 and Windows XP SP3
› Rugged and fanless design
› ECDIS-compliant models available
Power Input
CompactFlash
Card Socket
Power Switch
PS/2
Audio Output/Input
Gigabit Ethernet
Port x 2
USB 2.0
Port x 6
DVI-D/VGA Output
Serial Port x 2
(RS-232/422/485)
LED Indicators
(Storage, Power)
