22
Interrupt - This sets the IRQ used by MPU401 MIDI input. The
typical IRQ is 2/9. Note that IRQ 6 is also assigned to the floppy
drive but in some cases may be shared with the MPU. Use IRQ 6
as a last resort.
Windows 3.1x Utility Applications
The DMAN Windows 3.1x setup program creates a Windows
Group called Midiman Audio which contains several sound
utilities. In this section we will discuss these applications
through which you control sound within your system:
• The Audio Input Control Panel
• The Audio Mixer Control Panel
• The Audio Transport
• The Sound Check Application
Audio Input Control Panel
The Audio Input control panel lets you control the source,
amplitude and quality of sound coming into your system.
Clicking on the Audio Input icon nested in the Midiman Audio
group will present you with the Audio Input Control Panel
shown here.
Audio Input Controls
Buttons and control features of the Audio Input Control Panel are
as follows:
About - The About button brings up a window describing the
applet and its version.
