Autel Maxivideo MV101 8.5 мм [5/18] Accessories included

Dimensions

195 x 78.5 x 191.5mm

(7.68" x 3.09" x 7.54")

Weight

Net: 0.7 kg (1.5 lbs);

Gross: 1 kg (2.2 lbs) -- blister card;

2.3 kg (5 lbs) -- blow mold case

Cable reach

1m (3') -- expandable to 5m (16')

w/optional extensions

Imager head

diameter

16mm (0.63") / 8.5mm (0.33") is standard;

5.5mm (0.22") is optional

Waterproof

Imager head and cable to 3m (10')

Operating temp.

Main unit: 32°F to 113°F (0°C to 45°C);

Cable: 14°F to 176°F (-10°C to 80°C)

Storage temp.

-4°F to 158°F (-20°C to 70°C)

Operating

humidity

5% to 95% non-condensing (display unit)

Video output

RCA

2.3 Accessories Included

1) User’s Manual

2) Imager head and cable – 16mm, 8.5mm and 5.5mm diameter imager

head

3) Magnet, hook and mirror (Optional)

4) Video-out cable

5) 4 x AA batteries

6) Blister case or blow molded case -- there are two different packages

for the tool.

2.4 Tool Components

The MaxiVideo™ MV101 comes with the following items. Here

16mm diameter imager head and its matching accessories -- magnet,

hook and cable are shown below as an example.

Note: Because of continuing improvements, actual product may

differ slightly from photo.
