Appendix 2 - MIDI Implementation

Basic Channel Default 1 1

Changed 1 - 16 1 - 16

Function Transmitted Recognized Remarks

Mode Default 3 3

Message x x

Altered x x

Note Number True x x

Voice x x

Velocity Note ON x x

Note OFF x x

After Touch Keys x x

Channels x x

System Common Song Pos x x

Song Sel x x

Tune x x

System Real Time Clocks x x

Commands x x

Aux Messages Local ON/OFF x x

All Notes OFF x x

Active Sensing x x

System Reset x x

Pitch Bender xx

Control Change xx

Program Change 0 - 49 0 - 49 can be disabled

0 - 49 0 - 49

System Exclusive OO`

Notes:

Mode 1: OMNI ON, POLY Mode 3: OMNI ON, MONO O: Yes x: No

Mode 2: OMNI OFF, POLY Mode 4: OMNI OFF, MONO

DigiPatch 12x6

™

MIDI Implemetation Chart

Software Version 1.00
