7
Panels - Fig. 1
Panel Description
Front Panel
1. Program indicator: This normally displays the current program
number, but when the MIDI button is held it will display the
midi channel.
2. Target indicator: This normally displays the current target num-
ber, but when the MIDI button is held it will display the midi
thru ON / OFF status.
3. Source indicator: This displays the current source number.
When the MIDI button is held it will go blank.
4. Program Inc / Dec buttons: This pair of buttons is normally used
to select a new program, but when the MIDI button is held they
are used to select the midi channel.
5. Target Inc / Dec buttons: This pair of buttons is normally used to
select the current target, but when the MIDI button is held they
are used to select the midi thru ON / OFF status.
6. Source Inc / Dec buttons: This pair of buttons is used to select
the current source, but when the MIDI button is held they do
nothing.
7. MIDI button: This button behaves like a dead-man switch.
When you press and hold it the indicators and buttons perform
their alternative midi functions.
8. Store button: When you press this button the first time it will tell
the DigiPatch that you want to store the current program. If you
press it a second time the DigiPatch will execute the store opera-
tion. See the Operation section for more details.
