Programmable RTU Controllers
Ordering Information
Available Models
ioPAC 8020-5-RJ45-C-T: Modular RTU controller with RJ45 connectors, 5 I/O slots, C/C++, -40 to 75°C operating temperature
ioPAC 8020-5-M12-C-T: Modular RTU controller with M12 connectors, 5 I/O slots, C/C++, -40 to 75°C operating temperature
ioPAC 8020-9-RJ45-C-T: Modular RTU controller with RJ45 connectors, 9 I/O slots, C/C++, -40 to 75°C operating temperature
ioPAC 8020-9-M12-C-T: Modular RTU controller with M12 connectors, 9 I/O slots, C/C++, -40 to 75°C operating temperature
Optional Accessories (can be purchased separately)
WK-75: Wall-mount kit
I/O Modules (can be purchased separately)
RM-1602-T: ioPAC 8020 I/O module with 16 DIs, 24 VDC sink/source type, -40 to 75°C operating temperature
RM-1050-T: ioPAC 8020 I/O module with 10 DIs, 110 VDC isolated type, -40 to 75°C operating temperature
RM-2600-T: ioPAC 8020 I/O module with 16 DOs, 24 VDC sink type, -40 to 75°C operating temperature
RM-3802-T: ioPAC 8020 I/O module with 8 AIs, 4 to 20 mA, -40 to 75°C operating temperature
RM-3810-T: ioPAC 8020 I/O module with 8 AIs, 0 to 10 V, -40 to 75°C operating temperature
KM-2430-T: ioPAC 8020 communication module with 4-port Ethernet switch, M12 connectors, -40 to 75°C operating temperature
Note: Conformal coating available on request
Package Checklist
• ioPAC 8020-C
• Ethernet cable (M12 to RJ45 or RJ45 to RJ45)
• Serial console cable
• Documentation and software CD
Dimensions
Unit: mm (inch)
ioPAC 8020-9
Mounting Kits
Wall-mount kit
(optional)
Wall-mount kit
(optional)
DIN-rail kit DIN-rail kit
190.9 (7.52)
135 (5.31)
100 (3.94)
110 (4.33)
142.5 (5.61)
Wall-mount kit
(optional)
Wall-mount kit
(optional)
DIN-rail kit DIN-rail kit
190.9 (7.52)
135 (5.31)
100 (3.94)
110 (4.33)
142.5 (5.61)
292.5 (11.52)
135 (5.31)
100 (3.94)
110 (4.33)
