Moxa ioPAC 8500-2-RJ45-C-T [5/5] Port unmanaged ethernet switch module
![Moxa ioPAC 8500-2-RJ45-C-T [5/5] Port unmanaged ethernet switch module](/views2/1201397/page5/bg5.png)
5
Programmable RTU Controllers
© Moxa Inc. All Rights Reserved. Updated Aug. 5, 2014. Specifications subject to change without notice. Please visit our website for the most up-to-date product information.
KM-2430-T: 4-port unmanaged Ethernet switches, M12 connector
Standards:
IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseT(X)
IEEE 802.3x for Flow Control
Processing Type: Store and Forward
Interface: Front cabling, M12 connector, 10/100BaseT(X) auto negotiation speed
Operating Temperature: -40 to 75°C
Power Consumption: 20 mA @ 24 VDC
8-channel analog input modules, 16-bit resolution
4-port unmanaged Ethernet switch module
RM-3802-T: 8 analog inputs, 4 to 20 mA, 16 bits
Analog Inputs: 8 channels, differential
Input Range: 4 to 20 mA
Input Impendence: 120 ohms
Resolution: 16 bits, 0.24 μA/bit
Accuracy:
±0.1%, FSR @ 25°C
±0.3%, FSR @ -40°C, 75°C
Sampling Rate:
•Allchannels:12samples/sec
•Perchannel:1.5samples/sec
Isolation: 3k VDC or 2k Vrms
Operating Temperature: -40 to 75°C
Power Consumption: 78 mA @ 24 VDC
Wiring: I/O cable max. 14 AWG
MTBF: 1,222,361 hrs (Database: Telcordia/Bellcore)
RM-3810-T: 8 analog inputs, 0 to 10 V, 16 bits
Analog Inputs: 8 channels, differential
Input Range: 0 to 10 VDC
Input Impendence: 10M ohms (min.)
Resolution: 16 bits, 0.15 μA/bit
Data Format: 16-bit integer (2’s complement)
Accuracy:
±0.1%, FSR @ 25°C
±0.3%, FSR @ -40°C, 75°C
Sampling Rate:
•Allchannels:12samples/sec
•Perchannel:1.5samples/sec
Isolation: 3k VDC or 2k Vrms
Operating Temperature: -40 to 75°C
Power Consumption: 78 mA @ 24 VDC
Wiring: I/O cable max. 14 AWG
MTBF: 1,225,957 hrs (Database: Telcordia/Bellcore)
AI 0~10V
COMM
KM-2430-T
AI 4~20mA
