ioPAC RTU Software RTU Management
3-4
Now upgrade the file [85M-3800] for slot module
Now upgrade the file [85M-2600] for slot module
Now upgrade the file [85M-1602] for slot module
NOTE
The firmware upgrade contains the I/O modules firmware. If there is no compatible I/O modules installed, it will
automatically skip the I/O module firmware upgrading procedure
.
Recovering the Firmware
If the ioPAC RTU fails to boot up normally, the device firmware may be corrupt.
Follow the steps below to recover the device firmware:
1. Run a TFTP server on your PC.
2. Put the ioPAC RTU firmware file in the root folder of the TFTP server.
3. Power off the ioPAC RTU controller.
4. Connect the ioPAC RTU controller to the PC to the console port with a console cable, and to the LAN1 port
with an Ethernet cable.
5. Start a terminal program (e.g., PComm) with the settings: Baudrate 115200, no hardware flow control, 8
N 1; character set VT100.
6. Hold down the ESC key on your PC keyboard.
7. Power on the ioPAC RTU controller. You will be guided to the boot loader utility menu as shown below:
================================================================
==============
( 1) Network Configuration ( 2) Format User Disk
( 3) Firmware Upgrade ( 4) Reboot
================================================================
==============
Command>>3
8. Press 1 to configure the Network (e.g., TFTP server IP address and ioPAC RTU IP address).
9. Press 3 to upgrade the ioPAC RTU controller firmware.
10. Press 1 to select Load from LAN and then type the firmware filename to upgrade the device firmware.
================================================================
==============
( 1) Load from LAN ( 2) Load from serial with Xmodem
================================================================
==============
Command>>1
Please input load file name..
Default file name : RTU.hfm
User Input file name : RTU.hfm
Initializing network ...OK
Search TFTP Server...OK
Using default protocol (TFTP)
Ready to receive RTU.hfm
frm_headerlength : [0x5c]
frm_header_version : [0x2000000]
frm_modelname : [RTU]
frm_totallength : [0x96eed0]
frm_checksum : [0xe2c36f1f]
