ioPAC RTU Software RTU Management
3-3
1. Type the following commands to enable the RAM disk:
#upramdisk
#cd /mnt/ramdisk
2. Type the following commands to use the ioPAC RTU controller’s built-in FTP client to transfer the firmware
file (FWR_ioPAC_x_x_x.hfm) from the PC to the ioPAC RTU:
/mnt/ramdisk> ftp <destination PC’s IP> Login Name: xxxx
Login Password: xxxx
ftp> bin
ftp> get FWR_ioPAC_x_x_x.hfm
root@Moxa:~# ftp 192.168.127.3
Connected to 192.168.127.3.
220- Welcome to Rainbow FTP-G Server FREEWARE Edition.
220 *** For Personal Use Only!! ***
Name (192.168.127.3:root): root
331 Password required for root
Password:
230 User successfully logged in.
Remote system type is UNIX.
ftp> bin
200 Type set to BINARY
ftp> ls
200 Port command successful.
150 Opening ASCII mode data connection for directory list.
-rwx------ 1 user group 140856793 Apr 19 16:11 arm-linux_V1.0_Build2013041916.sh
-rwx------ 1 user group 6158672 Jan 11 10:31 FTP-G_x64.exe
-rwx------
1 user group 10053852 Apr 17 19:09 FWR_ioPAC8500_V1.1_Build13041719_STD.hfm
226 Transfer complete
ftp> get FWR_ioPAC8500_V1.1_Build13041719_STD.hfm /home/
FWR_ioPAC8500_V1.1_Build13041719_STD.hfm
local: /home/FWR.hfm remote: FWR_ioPAC8500_V1.1_Build13041719_STD.hfm
200 Port command successful.
150 Opening BINARY mode data connection for file transfer.
226 Transfer complete.
10053852 bytes received in 81.2 secs (1.2e+02 kbytes/sec)
ftp>
3. Next, use the upgradehfm command to upgrade the kernel and root file system.
# upgradehfm FWR_ioPAC_x_x_x.hfm
root@Moxa:/mnt/ramdisk# upgradehfm FWR_ioPAC8500_V1.1_Build13041719_STD.hfm
root@Moxa:/home# upgradehfm FWR_ioPAC8500_V1.1_Build13041719_STD.hfm
Upgrade firmware utility version 1.1.
To check source firmware file context.
The source firmware file conext is OK.
This step will destory all your firmware.
Continue ? (Y/N) :
Now upgrade the file [KERNEL_ioPAC-8500].
Format MTD device [/dev/mtd1] ...
MTD device [/dev/mtd1] erase 128 Kibyte @ 380000 -- 100% complete.
Wait to write file ...
Completed 100%
Now upgrade the file [ROOTFS_ioPAC-8500].
Format MTD device [/dev/mtd2] ...
MTD device [/dev/mtd2] erase 128 Kibyte @ 1000000 -- 100% complete.
Wait to write file ...
Completed 100%
Now upgrade the file [85M-5401] for slot module
Now upgrade the file [85M-3811] for slot module
Now upgrade the file [85M-3810] for slot module
Now upgrade the file [85M-3801] for slot module
