www.moxa.com

info@moxa.com

Industrial Cellular Solutions

OnCell 5004/5104-HSPA Series

Industrial ﬁve-band GSM/GPRS/EDGE/UMTS/HSPA cellular routers

The OnCell 5004/5104-HSPA series are high-performance industrial

grade cellular routers that allow up to 4 Ethernet-based devices

to simultaneously use a single cellular data account for primary

or backup network connectivity to remote sites and devices. Both

products provide the functionality of a cellular router, firewall, and

switch in one device, and to ensure zero data loss and on-demand

cellular communication, the OnCell 5004/5104-HSPA are integrated

with the GuaranLink function. The difference between the OnCell 5004-

HSPA and OnCell 5104-HSPA is that the OnCell 5104-HSPA comes

with a built-in relay output that can be configured to indicate the

priority of events when notifying or warning engineers in the field, and

the two digital inputs allow you to connect basic I/O devices, such as

sensors, to the cellular network. The OnCell 5004-HSPA can be placed

on a desktop or wall-mounted, whereas the OnCell 5104-HSPA has an

IA design and can be attached to a DIN rail. Both products use 12 to

48 VDC power inputs with a screw-on design for greater reliability, and

the Ethernet ports come with 1.5 kV magnetic isolation protection to

keep your system safe from unexpected electrical discharges.

OnCell 5004-HSPA Series OnCell 5104-HSPA Series

Speciﬁcations

Overview

› Five band UMTS/HSPA 800/850/AWS/1900/2100 MHz

› Quad-band GSM/GPRS/EDGE 850/900/1800/1900 MHz

› Cellular WAN and Ethernet WAN backup mechanism for a

complete path redundancy

› Primary and secondary power inputs for power source

redundancy

› GuaranLink and dual SIM redundancy for continuous cellular

connections

› Connect to 4 10/100BaseT(X) devices over an integrated VPN

› Centralize private IP management with OnCell Central Manager

› DIN rail and wall mountable housing

› 2 digital inputs and 1 relay output (OnCell 5104-HSPA only)

Standards: GSM/GPRS/EDGE/UMTS/HSPA

Band Options:

• Five-band UMTS/HSPA 800/850/AWS/1900/2100 MHz

• Quad-band GSM/GPRS/EDGE 850/900/1800/1900 MHz

HSPA Data Rate: 14.4 Mbps DL, 5.76 Mbps UL

EDGE Multi-slot Class: Class 12

EDGE Data Rate: 237 Kbps DL, 237 Kbps UL

EDGE Terminal Device Class: Class B

GPRS Multi-slot Class: Class 12

GPRS Data Rate: 85.6 Kbps DL, 85.6 Kbps UL

GPRS Terminal Device Class: Class B

GPRS Coding Schemes: CS1 to CS4

Tx Power:

UMTS/HSPA: 0.25 W

EDGE900: 0.5 W

EDGE1800: 0.4 W

GSM1800: 1 W

GSM900: 2 W

WAN Interface

Number of Ports: 1

Ethernet: 10/100 Mbps, RJ45 connector, Auto MDI/MDIX

LAN Interface

Number of Ports: 4

Ethernet: 10/100 Mbps, RJ45 connector, auto MDI/MDIX

SIM Interface

Number of SIMs: 2

SIM Control: 3 V

I/O Interface (OnCell 5104-HSPA)

Alarm Contact: 1 relay output with current carrying capacity of 1 A @

24 VDC

Digital Inputs: 2 electrically isolated inputs

• +13 to +30 V for state “1” (On)

• +3 to -30 V for state “0” (Off)

Software

Network Protocols: ARP, DDNS, DHCP/BOOTP, DNS Relay, HTTP,

HTTPS, ICMP, IPSec, PPP, PPPoE, SMTP, SNTP, SSL, TCP/IP, Telnet,

UDP

Routing/Firewall: NAT, port forwarding, WAN IP ltering, static route

Authentication: Local user-name and password

Cellular Connectivity: GuaranLink

Management Software

Utilities: OnCell Search Utility

Conﬁguration and Management Options: SNMP v1/v2c/v3, Web/

Telnet/Serial Console, SSH, Remote SMS Control, Auto IP Report

Private IP Solution: OnCell Central Manager
