Industrial Cellular Solutions
1
www.moxa.com
Industrial 802.11n/HSPA wireless router
› Universal GSM/GPRS/HSPA 2G/3G cellular communication
› 2.4/5 GHz 300 Mbps WiFi communication
› Built-in high speed 4-port Ethernet switch
› Industrial design with dual power inputs and built-in DI/DO
support
› Cellular link redundancy with dual-SIM GuaranLink support
› Antenna and power isolation design to protect against
interference
WDR-3124A Series
The WDR-3124A industrial wireless router combines 802.11n and
cellular technologies to provide flexible wireless network connectivity.
The WDR-3124A comes with a built-in antenna and power isolation
suitable for any harsh industrial environment. With DIN-rail mounting,
wide operating temperature range models, and IP30 housing, the
WDR-3124A is a convenient yet reliable solution for any industrial
wireless application.
Specifications
Introduction
Cellular Interface
Standards: GSM/GPRS/EDGE/UMTS/HSPA
Band Options:
• Five-band UMTS/HSPA 800/850/900/1900/2100 MHz
• Quad-band GSM/GPRS/EDGE 850/900/1800/1900 MHz
HSPA Data Rate:
• Downlink: Up to 14.4 Mbps
• Uplink: Up to 5.76 Mbps (Category 6, 7)
GPRS Data Rate: Downlink/Uplink: 236 kbps (Class 12)
Wireless Interface
Standards:
IEEE 802.11a/b/g/n for Wireless LAN
IEEE 802.11i for Wireless Security
Spread Spectrum and Modulation (typical):
• DSSS with DBPSK, DQPSK, CCK
• OFDM with BPSK, QPSK, 16QAM, 64QAM
• 802.11b: CCK @ 11/5.5 Mbps, DQPSK @ 2 Mbps, DBPSK @ 1 Mbps
• 802.11a/g: 64QAM @ 54/48 Mbps, 16QAM @ 36/24 Mbps, QPSK @
18/12 Mbps, BPSK @ 9/6 Mbps
• 802.11n: 64QAM @ 300 Mbps to BPSK @ 6.5 Mbps (multiple rates
supported)
Operating Channels (central frequency):
WDR-3124A-EU:
2.412 to 2.472 GHz (13 channels)
5.180 to 5.240 GHz (4 channels)
WDR-3124A-US:
2.412 to 2.462 GHz (11 channels)
5.180 to 5.240 (4 channels)
5.745 to 5.825 GHz (5 channels)
Security:
• SSID broadcast enable/disable
• 64-bit and 128-bit WEP encryption, WPA /WPA2-Personal and
Enterprise (IEEE 802.1X/RADIUS, TKIP and AES)
Transmission Rates:
802.11b: 1, 2, 5.5, 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: 6.5 to 300 Mbps (multiple rates supported)
WLAN and Cellular Connectivity
• High-speed wireless connectivity at up to 300 Mbps
• WLAN AP/Client-Router operation mode support
• Universal cellular band support for GSM/GPRS/HSPA 3G
connectivity
Effective Isolation and Redundancy Design
• Dual power input for power redundancy
• Dual SIM support for cellular connection redundancy
• Antenna isolation for protection against radio interference
• Power isolation for power source insulation protection
