Moxa WDR-3124A-EU [3/3] Ordering information

Industrial Cellular Solutions

Dimensions

Unit: mm (inch)

Ordering Information

62.5 (2.46)

66.3 (2.61)

29.9 (1.18)

124 (4.88)

90 (3.54)

Rear View Left Side View

Front View

Top & Bottom View

Available Models

WDR-3124A-US: Industrial 802.11n/HSPA wireless router, WiFi US band, 0 to 55°C operating temperature

WDR-3124A-US-T: Industrial 802.11n/HSPA wireless router, WiFi US band, -30 to 70°C operating

temperature

WDR-3124A-EU: Industrial 802.11n/HSPA wireless router, WiFi EU band, 0 to 55°C operating temperature

WDR-3124A-EU-T: Industrial 802.11n/HSPA wireless router, WiFi EU band, -30 to 70°C operating

temperature

Note: Visit Moxa’s website for a complete list of optional wireless accessories and antennas available for

Moxa’s wireless products.

Package Checklist

• WDR-3124A wireless router

• 2 dual-band omni-directional

antennas, 2 dBi, RP-SMA (male)

• 1 2G/3G omni-directional

antenna, 2 dBi, SMA (male)

• 5 plastic RJ45 protective caps for

serial console and Ethernet ports

• Quick installation guide (printed)

• Warranty card
