Industrial Cellular Solutions
2
www.moxa.com
TX Transmit Power:
2.4 GHz
802.11b:
Typ. 23±1.5 dBm @ 1 Mbps
Typ. 20±1.5 dBm @ 5 Mbps
Typ. 19±1.5 dBm @ 11 Mbps
802.11g:
Typ. 20±1.5 dBm @ 6 to 24 Mbps
Typ. 19±1.5 dBm @ 36 Mbps
Typ. 18±1.5 dBm @ 48 Mbps
Typ. 17±1.5 dBm @ 54 Mbps
5 GHz
802.11a:
Typ. 20±1.5 dBm @ 6 to 24 Mbps
Typ. 19±1.5 dBm @ 36 Mbps
Typ. 16±1.5 dBm @ 48 Mbps
Typ. 15±1.5 dBm @ 54 Mbps
802.11n:
MCS0, 8 @ 20MHz: Typ. 19 dBm (± 1.5 dBm)
MCS0, 8 @ 40 MHz: Typ. 18 dBm (± 1.5 dBm)
MCS7, 15 @ 20 MHz: Typ. 14 dBm (± 1.5 dBm)
MCS7, 15 @ 40 MHz: Typ. 14 dBm (± 1.5 dBm)
RX Sensitivity:
2.4 GHz
802.11b:
-92 dBm @ 1 Mbps
-90 dBm @ 2 Mbps
-88 dBm @ 5.5 Mbps
-84 dBm @ 11 Mbps
802.11g:
-87 dBm @ 6 Mbps
-86 dBm @ 9 Mbps
-85 dBm @ 12 Mbps
-82 dBm @ 18 Mbps
-80 dBm @ 24 Mbps
-76 dBm @ 36 Mbps
-74 dBm @ 48 Mbps
-72 dBm @ 54 Mbps
802.11n:
-69 dBm @ MCS15 20MHz
-71 dBm @ MCS7 20MHz
5 GHz
802.11a:
-87 dBm @ 6 Mbps
-86 dBm @ 9 Mbps
-85 dBm @ 12 Mbps
-82 dBm @ 18 Mbps
-80 dBm @ 24 Mbps
-76 dBm @ 36 Mbps
-74 dBm @ 48 Mbps
-72 dBm @ 54 Mbps
802.11n:
-69 dBm @ MCS15 20MHz
-68 dBm @ MCS15 40MHz
-71 dBm @ MCS7 20MHz
-70 dBm @ MCS7 40MHz
LAN Interface
Standards:
IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseTX
IEEE 802.3ab for 1000BaseT
Speed: 10/100/1000 Mbps, Auto MDI/MDIX
Interface
Cellular Antenna Connector: 1 SMA (female) for WCDMA
Wireless Antenna Connectors: 2 RP-SMA (female)
GNSS: 1 SMA (female), GPS (1575.42 MHz), GLONASS (1602 MHz)
Ethernet: 4, 10/100/1000Mbps auto negotiation speed, F/H duplex
mode and auto MDI/MDI-X connection (RJ45-type)
Serial Console Port: 1, RS-232 (RJ45)
Alarm Contact: 1 relay output with current carrying capacity of 1 A @
24 VDC
Digital Inputs:
2 electrically isolated inputs
+13 to +30 V for state “1”
+3 to -30 V for state “0”
Power Input: Dual input, 12-48VDC
LED Indicators: PWR1, PWR2, STATUS, FAULT, CELLULAR SIGNAL,
WIFI SIGNAL, WLAN, SIM1, SIM2, 2G, 3G, GPS
Ground Screw: M5
Reset Button: Power Reset/Factory Default Reset
Software
Network Protocols: ICMP, TCP/IP, UDP, DHCP, Telnet, DNS, SNMP,
HTTP, HTTPS, SMTP, SNTP, ARP
Routing/Firewall: NAT, Port Forwarding, IP/MAC/Port Filtering
VPN:
• Max. Tunnel Number: 5 (Responder/Initiator)
• IPSec (DES, 3DES, AES, MD5, SHA-1, DH2, DH5), PSK/X.509/RSA
GPS: NMEA
Others: DDNS
Management Software (Moxa Proprietary)
GuaranLink: 4-tier heart-beat for reliable and persistent cellular
connectivity
OnCell Central Management: Large scale centralized device
management over private cellular IPs
Search Utility: Simple device configuration and management
SIM Interface
Number of SIMs: 2
SIM Control: 3 V
Physical Characteristics
Housing: Aluminum, providing IP30 protection
Weight: 1280 g
Installation: DIN-rail (default) or wall-mount (optional)
Dimensions: 67 x 90.5 x 124 mm (2.6 x 3.52 x 4.83 inch)
Environmental Limits
Operating Temperature:
Standard Models: 0 to 55°C (0 to 131°F)
Wide Temp. Models:-30 to 70°C (-22 to 158°F)
Storage Temperature: -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity: 5 to 95% (30°C, non-condensing)
Power Requirements
Input Voltage: 12 to 48 VDC, redundant dual inputs
Connector: 4-pin removable terminal block
Power Consumption: 9.6W (12V/0.7A to 48V/0.2A)
Reverse Polarity Protection: Present
Standards and Certifications
Safety: EN 60950-1, UL 60950-1
EMC:
FCC Part 15 Subpart B
EN 61000-6-2/-4
Radio:
EN 301 489-1, EN 301 489-7, EN 301 511, EN 301 908, EN 300 328,
EN 301 893
Reliability
MTBF (mean time between failures): 382,851 hours
Warranty
Warranty Period: 5 years
Details: See www.moxa.com/warranty
