- 12 -
Specifications
Cellular Interface
Standards
GSM/GPRS/EDGE/UMTS/HSPA
Band Options WDR-3124A-EU/US: Five band UMTS/HSPA
800/850/900/1900/2100 MHz
WDR-3124A-EU/US: Quad-band GSM/GPRS/EDGE
850/900/1800/1900 MHz
HSPA Data Rate Downlink: Up to 14.4 Mbps
Uplink: Up to 5.76 Mbps
(category 6, 7)
GPRS Data Rate
Downlink/Uplink: 236 kbps (class 12)
SMS
Point-to-point MT and MO
PDU mode
Interface
Cellular Antenna
Connectors
1 SMA (female) for WCDMA
Wireless Antenna
Connectors
2 RP-SMA (female)
GNSS
(GPS+GLONASS)
1 SMA (female),
GPS: 1575.42 MHz
GLONASS: 1602 MHz
SIM Slots
Dual SIM card support
Ethernet 4, 10/100/1000Mbps auto negotiation speed, F/H
duplex mode and auto MDI/MDI-X connection
(RJ45-type)
Serial Console Port
1, RS-232 (RJ45-type)
LED Indicators
PWR1, PWR2, STATE, FAULT, CELLULAR SIGNAL,
WIFI SIGNAL, WLAN, SIM1, SIM2, 2G, 3G, GPS
Alarm Contact 1 relay output with current carrying capacity of 1 A @
24 VDC
Digital Inputs
2 electrically isolated inputs
+13 to +30 V for state “1”
+3 to -30 V for state “0”
Ground Screw
M5
Reset Button
Power Reset/Factory Default Reset
WLAN Interface
Standards
IEEE 802.11a/b/g/n for Wireless LAN
IEEE 802.11i for Wireless Security
Spread Spectrum
and
Modulation
(typical)
DSSS with DBPSK, DQPSK, CCK
OFDM with BPSK, QPSK, 16QAM, 64QAM
802.11b:
- CCK @ 11/5.5 Mbps
- DQPSK @ 2 Mbps
- DBPSK @ 1 Mbps
802.11a/g:
- 64QAM @ 54/48 Mbps
- 16QAM @ 36/24 Mbps
- QPSK @ 18/12 Mbps
- BPSK @ 9/6 Mbps
802.11n:
-
64QAM @ 300 Mbps to BPSK @ 6.5 Mbps (multiple
rates supported)
