IW Accessories
1
© Moxa Inc. All Rights Reserved. Updated Dec. 14, 2011. Specifications subject to change without notice. Please visit our website for the most up-to-date product information.
Ø6.70
Ø29.40
83.00±0.5025.50
110±2.010
250±3.5 cm2C
ANT-WCDMA-AHSM-04-2.5m
Five-band GSM/GPRS/EDGE/UMTS/HSPA, 4 dBi, omni-directional,
magnetic base antenna
Specifications
Ordering Information
Antenna Characteristics
Frequency: 850/900/1800/1900/2100 MHz
Anntenna Type: Omni-directional
Typical Antenna Gain: 4 dBi
Connector: SMA (male)
Impedance: 50 ohms
Polarization: Linear, vertical
HPBW/horizontal: 360°
V.S.W.R.: <2
Physical Characteristics
Weight: 60 g
Dimensions: Length=110 mm
Cable Length: 2.5 m
Cable Type: RG174
Radome Color: Black
Radome Material: Plastic
Installation: Straight mount
Environmental Limits
Operating Temperature: -30 to 75°F (-22 to 167°F)
Storage Temperature: -30 to 75°C (-22 to 167°F)
Ambient Relative Humidity: 5 to 95% (30°C, non-condensing)
Warranty
Warranty Period: 1 year
Details: See www.moxa.com/warranty
Dimensions
Unit: mm (inch)
Available Models
ANT-WCDMA-AHSM-04-2.5m: Five-band GSM/GPRS/UMTS/HSDPA, omni-directional, 4 dBi, 11 cm height, magnetic SMA, 2.5 m
Can be used with the following products
OnCell G2111/G2151I, OnCell G3111/G3151, OnCell G3211/G3251, OnCell G3100 Series, OnCell G3100-HSDPA Series, OnCell G3100-HSPA
Series, OnCell 5000 Series, OnCell 5000-HSDPA Series, OnCell G5000-HSPA Series
› High gain antenna
› Small size for compact fit
› Lightweight for portable deployment
› Magnetic base mount
› SMA connector (male) supported
