Moxa VPort 36-1MP [29/78] Firmware upgrade

VPort 36-1MP System Configuration

4-8

Firmware Upgrade

Take the following steps to upgrade the firmware:

Step 1:

Press the

Browse button to select the firmware file.

NOTE

For the VPort 36

-1MP, the firmware file extension should be .rom.

Step 2:

Click on the

Upgrade button to upload the firmware to the VPort.

Step 3:

The system will start to run the firmware upgrade process.

Step 4:

Once

Firmware Update Success…..Reboot.... is displayed, please wait a few seconds for the

VPort to reboot. The reboot process is finished once the

STAT LED is lit continuously in green.

NOTE

Upgrading the firmware will not change the original settings.

Reset to Factory Default

From the “Reset to Factory Default” page, click on OK (as shown in the following figure) to reset the VPort to

its factory default settings.

NOTE

All parameters will be reset to factory defaults when you use the

Factory Default function. For this reason,

you want to keep a digital copy of the current configuration, remember to export the sys_config.ini file before

using the Factory Default function.

Reboot

From the “Device Reboot” page, click OK (as shown in the following figure) to restart the VPort’s system.
