VPort 36-1MP System Configuration

4-32

Once Digital PTZ is enabled, click Show PTZ Control Panel from the IP camera home page. Click the “+”

button in the bottom right of the page to use the digital zoom function. After zooming in, you can then use the

wheel shown below to navigate the camera image.

NOTE

The direction button in the wheel will not be displayed until a digital zoom is performed. Once the camera image

is zoomed out to its original size, the direction

button will disappear.

NOTE

The VPort 36

1MP supports up to 4x digital zoom. Press the “+” button to view a 2x zoomed image, and twice

to view a 4x zoomed image.

DynaStream

DynaSteam

is a unique and innovative function that allows for adaptive frame rates in response to events on

the network, such as event triggers and system commands. When network traffic becomes congested,

DynaStream™ allows VPort products to respond to CGI, SNMP, and Modbus commands from SCADA systems

(as well as the MxNVR-MO4’s VMD, DI, CGI events, and video loss triggers) and automatically decrease the

frame rates to reduce bandwidth consumption. This reserves bandwidth for the SCADA system to maintain

Quality of Service (QoS) and guarantees that the SCADA performance will not be impacted by video traffic. For

example, the frame rate can be set low during regular streaming to reduce bandwidth usage and automatically

switched to a high frame rate during triggered events to ensure quick transmission of critical video data or

video streams, or to provide detailed visual images for problem analysis.

NOTE

To enable the DynaStream function from CGI commands and Modbus TCP, refer to the CGI Commands User’s

Manual for VPort

SDK PLUS.
