DMP3 | User Guide
8
Specifications
WARNING: This product contains chemicals, including lead, known to the State of
California to cause cancer, and birth defects or other reproductive harm.
Wash hands
after handling.
© 2008 Avid Technology, Inc. All rights reserved. Product features, specifications,
system requirements and availability are subject to c
hange without notice. Avid,
M-Audio and D
M
P3 are either trademarks or registered trademarks of A
vid T
ec
hnology,
Inc. All other trademarks contained herein are the property of their respective owners.
DMP3
Tested to comply with
FCC standards
FOR HOME OR STUDIO USE
Maximum Input: +10 dBv
Maximum Output - Balanced: +22 dBv
Maximum Output - Unbalanced: +16 dBv
Headroom: 22 dB
Meter headroom: 12 dB
Meter level: 0 VU @ +12dBV, 1KHz
Maximum Gain - Mic/Instr. In: 66 dB
Gain Range: 13dB to 73dB
Clip Indicator: 3 dB below threshold of clipping
Low Cut Filter Cutoff: 3 dB down @ 72 Hz
Low Cut Filter Slope: 18 dB/Octave
Input Impedance (1 kHz) - Mic In: 3 kOhms
Input Impedance (1 kHz) - Instr. In: 100 kOhms
Noise Factor: < 1.5dB @ maximum gain
Signal to noise: 115dB “A” weighted @ minimum gain
THD: 0.02% @ minimum gain (THD is below
noise floor at most higher gain settings)
Frequency response: 20Hz to 80KHz; +0; -1 dB
Weight: Under l lb.
Power Supply: 9vAC 1Amp supply w/2.5mm plug.
Output Impedance: 500 Ohms.
