- 3 -
NOTE
This product must be installed in compliance with your local laws
and regulations.
Features
• Maximum 60 FPS @ full HD (1080P, 1920x1080) resolution (only in
single stream mode)
• 22X/30X optical and 20X digital zoom (22X: 4.3 to 94.6 mm,
30X: 4.3 to 129 mm)
• Supports MJPEG and H.264 dual codecs
• Supports Full HD/SXGA/WXGA/720P/SVGA/ Full D1/ 4CIF/ VGA/
CIF/QVGA resolution
• TCP, UDP, and HTTP network transmission modes
• Supports QoS (ToS) for transmission priority
• Supports RTSP streaming
• Supports multicast (IGMP) video streaming
• Supports SNMP (V1/V2C/V3) for network system integration and
management
• Accessible IP filtering
• UPnP supported
• Built-in web server for easy configuration
• 360° endless pan and -6° to +96° tilt
• Manual max pan speed of 120°/s; Preset max of 255°/s; Alarm
Trigger max of 360°/s*
• Supports PTZ movement calibration
• Minimum illumination up to 0.4 lux (color) and 0.03 lux (B/W)
• Built-in tamper alarm and Video Motion Detection (VMD)
• -40 to 65°C operating temperature
• 1 10/100BaseT(X) port with RJ45 connector
• IP66 protection and NEMA Type 4X form factor
• SDXC slot for local event / disconnected recording
• CBR Pro for flexible flow control
• DynaStream™ for network efficiency with dynamic frame rate change
• EN50121-4 compliance
• Supports ONVIF Profile S for multiple video stream profiles
• 24 VDC/VAC power input
• Supports NTCIP 1205
• EN 62262 IK10 level vandal resistance
• CE, FCC, UL 60950-1
• Pre, Trigger, and post snapshot images supported
• Sequential snapshot images supported
• Supports SMTP and FTP for alarm message transmission
• Supports HTTP event server
• 3-year warranty for product, and 1-year warranty for moving parts**
*
When the temperature is under -10°C, the maximum PT speed will be
reduced to a max. of 130°/sec.
**
The following moving parts come with a 1-year warranty:
•
Fan
•
Shutter
•
Zoom lens
•
DC-Iris, P-Iris lens
•
PAN, TILT and lens motors/ mechanism
• Slip ring
