Moxa VPort 66 [7/15] Hardware installation

• Safety Rope: For easier installation, use the safety rope to hook the

camera to the mounting kit buckle.

Hardware Installation

A mounting kit is required to install the VPort 66-2MP. Below we use the

VP-520LB to illustrate; the installation method of other accessories is

Step 1: Open and remove the top cover.

Use the security torx to loosen the 4 top cover screws.

Step 2: Installing an SD card requires removing the camera

1. Loosen the 2 anti-drop Phillips screws, which hold the camera

module in place.
