VPort ONVIF Profile S System Configuration

4-21

(The model supporting IPv6 would have this list)

Accessible IP Settings allow you to add or remove “Legal” remote host IP addresses to prevent unauthorized

access. Access to the VPort is controlled by IP address. That is, if a host’s IP address is in the accessible IP table,

then the host will be allowed access to the VPort. In particular, an IP together with a NetMask is used to

specify a range of IP addresses. Here are some examples:

• Allow only one host with a specific “IP address” to access the VPort. For example,

IP = 192.168.1.16 NetMask = 255.255.255.255

will only allow the host with IP = 192.168.1.16 to access the VPort.

• Allow all hosts on a specific subnet to access the VPort. For example:

IP = 192.168.1.0 NetMask = 255.255.255.0

will allow all hosts with IP addresses of the form 192.168.1.xxx to access the VPort.

• Allow any host to access the VPort.

Do not checkmark the “Enable accessible IP list” checkbox.

The following table gives additional IP/NetMask configuration examples.

Allowable Hosts Input Formats

Any host

Disable

192.168.1.120 192.168.1.120/255.255.255.255

192.168.1.1 to 192.168.1.254 192.168.1.0/255.255.255.0

192.168.0.1 to 192.168.255.254 192.168.0.0/255.255.0.0

192.168.1.1 to 192.168.1.126 192.168.1.0/255.255.255.128

192.168.1.129 to 192.168.1.254 192.168.1.128/255.255.255.128

SNMP

The VPort supports three SNMP protocols. The available protocols are SNMP V1, SNMP V2c, and SNMP V3.

SNMP V1 and SNMP V2c use a community string match for authentication, which means that SNMP servers

access all objects with read-only or read/write permissions using the community string public/private (default

value). SNMP V3, which requires you to select an authentication level of MD5 or SHA, is the most secure

protocol. You can also enable data encryption to enhance data security. SNMP security modes and security

levels supported by the VPort are shown in the following table. Select one of these options to communicate

between the SNMP agent and manager.
