VPort P06HC-1MP-M12 System Configuration

4-10

integration much more convenient. For different connection types, the access name is different. For UDP and

TCP streams, the access name is udpStream. For HTTP streams, the access name is

moxa-cgi/udpstream_ch<channel number>. For multicast streams, the access name is

multicastStream_ch<channel number>. You can access the media through the following URL:

rtsp://<IP address>:<RTSP port>/<Access name> for software that supports RTSP.

Setting Description Default

RTSP Port An RTSP port is similar to an HTTP port, which can enable the

connection of video/audio streams by RTSP.

554

The VLC media player is used here to illustrate an RTSP streaming application:

Step 1:

Open

VLC Player and select Media - Open network streaming

Step 2:

When the following pop

-up window appears, type the URL in the input box. E.g., type

rtsp://<VPort P06HC

-1MP-

M12’s IP address>[:<RTSP Port]/udpstream_ch1_stream< 1

or 2>

rtsp://<

VPort P06HC-1MP-M12’s IP address>[:<RTSP Port]/multicaststream_

ch1_stream<1 or

RTSP Port: 554

is the default, and then click on OK to connect to the VPort P06HC-1MP-M12.

Step 3:

Wait a few seconds for

VLC Player to establish the connection.
