IP Surveillance
1
www.moxa.com
VPort P06HC-1MP-M12 Series
HD video image, square-type IP cameras for mobile surveillance
The VPort P06HC-1MP-M12 square-type IP cameras provide an HD
(720P, 1280 x 720) video image, and feature 3 H.264/MJPEG video
streams, giving them the versatility and ruggedness to excel in many
different installations and environments for IP video surveillance
applications. In addition, the cameras comply with a portion of EN
50155 specifications, covering operating temperature, power input
Introduction
› Compliant with EN 50121-3-2 and essential sections of EN 50155*
› -25 to 55°C operating temperature
› 1/2.7” progressive scan camera with maximum 1280 x 800
resolution at up to 30 frames/second
› Flush mounting for hiding inside a panel, such as a wall or ceiling
› Up to 3 H.264 or MJPEG independent video streams
› DynaStream™ support for maximized network efficiency
› CBR Pro™ support for high image quality in limited bandwidth
transmissions
› Supports DHCP Opt 66/67 for auto-configuration
› 1 built-in microphone for audio input, and 1 digital input for
external sensor
› ONVIF support for standardization and interoperability
*Moxa defines “essential compliance” to include those EN 50155 requirements
that make products more suitable for rolling stock railway applications.
voltage, surge, ESD, and vibration, making them suitable for a variety
of industrial applications. The cameras feature a -25 to 55°C operating
temperature, a rugged M12 Ethernet port, 1 built-in microphone, 1
digital input, PoE power inputs, IP66 rain and dust protection, and a
selectable lens.
Camera
Sensor: 1/2.7” HD progressive scan CMOS
Lens: 3.6 mm megapixel fixed focal length lens
Angle of View:
• 3.6 mm, F1.6: Diagonal 120°, Horizontal 96°, Vertical 56°
Synchronization: Internal
Minimum Illumination: 0.2 Lux @ F=1.2
White Balance: ATW/AWB
Electronic Shutter: Auto (1/30 to 1/25000 sec)
S/N Ratio: 50 dB (Gamma, Aperture, AGC, OFF; DNR ON)
DNR: Built-in DNR
WDR: Level 1-3, up to 115 dB
AGC Control: 2X, 4X, 8X, 16X
Flickerless Control: Automatic/50 Hz/60 Hz mode
Auto Exposure: Level ±5
Image Rotation: Flip, Mirror, and 180° rotation
Image Setting: Manual tuning with brightness and contrast
Video
Video Compression: H.264 (ISO/IEC 14496-10) or MJPEG
Video Output: Via Ethernet
Video Streams: 3 independent H.264 or MJPEG video streams
• Stream 1: H.264, 1280 x 800 resolution (max.)
• Stream 2: H.264, 720 x 576 resolution (max.)
• Stream 3: MJPEG, 720 x 576 resolution (max.)
Note: Streams 2 and 3 must be set to the same resolution
Video Resolution and FPS (frames per second):
NTSC PAL
Size Max. FPS Size Max. FPS
CIF
352 x 240 30 352 x 288 25
VGA
640 x 480 30 640 x 480 25
4CIF
704 x 480 30 704 x 576 25
Full D1
720 x 480 30 720 x 576 25
SVGA
800 x 600 30 800 x 600 25
HD
1280 x 720 30 1280 x 720 25
WXGA
1280 x 800 30 1280 x 800 25
Video Viewing:
• DynaStream™ support for automatic frame rate adjustment
• CBR Pro™ for good image quality in limited bandwidth transmission
• 3 privacy mask areas congurable
• Adjustable image size and quality
• Timestamp and text overlay
• OSD (On screen Display) position adjustable
• Maximum of 5 simultaneous unicast connections
• Digital PTZ with 4x zoom
Audio
Audio Inputs: 1, built-in microphone
Audio Format: Mono, PCM (G.711)
Specifications
