Moxa VPort P06HC-1MP-M12-CAM36-CT [2/3] Alarms

Moxa VPort P06HC-1MP-M12-CAM25 [2/3] Alarms
IP Surveillance
2
www.moxa.com
Network
Protocols: TCP/IP, UDP, HTTP, SMTP, NTP, DNS, DHCP, UPnP, RTP,
RTSP, ICMP, QoS,IGMPv3, SNMPv1/v2c/v3, DDNS, TFTP, ARP, DHCP,
OPT66/67
Ethernet: 1 10/100BaseT(X) isolated Ethernet port, 4-pin M12 D-coded
female connector
GPIO
Digital Inputs: 1, max. 8 mA, isolated 5-pin M12 connector
High: +13 V to +30 V; Low: -30 V to +3 V
Power Requirements
Input: Power-over-Ethernet (IEEE 802.3af)
Power Consumption: 6 W (max.)
Physical Characteristics
Housing: IP66 metal housing with transparent cover
Dimensions: 109 x 68 x 90 mm (4.29 x 2.68 x 3.54 in)
Weight: 903 g (1.1 lb)
Installation: Flush mounting
Alarms
Intelligent Video: Camera tamper
Video Motion Detection: 3 independently configurable motion areas
Scheduling: Daily repeat timing schedule
Imaging: JPEG snapshots for pre/trigger/post alarm images
Custom Alarms: HTTP event servers for setting customized alarm
actions
Email/FTP Messaging: Automatic transfer of stored images via email
or FTP as event-triggered actions
Pre-alarm Buffer: 12 MB video buffer for JPEG snapshot images
Security
Password: User level password protection
Filtering: By IP address
Encryption: HTTPS, SSH
Environmental Limits
Operating Temperature: -25 to 55°C (-13 to 131°F)
Storage Temperature: -40 to 75°C (-40 to 167°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Altitude: 2000 m
Conformal Coating: Available on request
Standards and Certifications
Safety: UL 60950-1
Rail Traffic: EN 50155 (essential compliance*), EN 45545-2
EMI: FCC Part 15, CISPR (EN 55022) class A
EMS:
IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 20 V/m
IEC 61000-4-4 EFT: Power: 2 kV; Signal: 2 kV
IEC 61000-4-5 Surge: Power: 2 kV; Signal: 2 kV
IEC 61000-4-6 CS: 10 V
IEC 61000-4-8
*Moxa defines “essential compliance” to include those EN 50155 requirements
that make products more suitable for rolling stock railway applications.
Shock: IEC 61373
Freefall: IEC 60068-2-32
Vibration: IEC 61373
Note: Please check Moxa’s website for the most up-to-date certication status.
Warranty
Warranty Period: 5 years
Details: See www.moxa.com/warranty
Minimum Viewing System Requirements
CPU: Pentium 4, 2.4 GHz
Memory: 512 MB of memory
OS: Windows XP/2000 with SP4 or above, Windows Vista, Windows 7
Browser: Internet Explorer 9.x or above
Multimedia: DirectX 9.0c or above
Software Development
VPort SDK PLUS: Includes CGI commands, ActiveX Control, and API
library for customized applications or system integration for third-party
developers (the latest version of SDK is available for download from
Moxa’s website).
Standard: ONVIF
