VPort ONVIF Profile S System Configuration

4-33

action, which means that a large variety of different PTZ cameras can be used with the VPort video encoders

and their supported PTZ control panel or joystick.

NOTE

The legacy PTZ control panel or joystick should be connected to the VPort’s PTZ port or the COM port of a PC.

But, when it is connected to a PC’s COM port, you will need to install a real COM driver on the PC and map the

COM ports. For detailed information, refer to the VPort SDK PLUS

ActiveX Control SDK for the Real COM driver

and COM port map

ping function sample codes. You can download this SDK from Moxa’s website

(www.moxa.com).

Specific PTZ Driver:

A PTZ driver is usually required to control a PTZ camera over a TCP/IP network. This is because each PTZ

camera supplier has their own proprietary PTZ control protocol. VPort video encoders support all popular PTZ

drivers for controlling PTZ cameras.

Setting Description Default

Control Mode Select the PTZ control mode in Transparent PTZ Control or

PTZ Driver

PTZ driver

The configurations described below are only available in PTZ Driver mode.

Port Settings

Setting Description Default

Baud rate (bps) The baud rate specified by the PTZ camera’s serial

communication specs.

2400

Data bits

The parameters used to define the serial communication.

Stop bits 1

Parity bits None

PTZ Camera Drivers

VPort products come with PTZ camera drivers for some of the popular PTZ cameras. Administrators can select

the correct PTZ driver in the “Select the Camera Driver” menu. If the attached PTZ camera is not supported by

the VPort, administrators can use the Custom Camera function to enter the proprietary commands for pan, tilt,

zoom, and focus control.

Setting Description Default

Select the camera

driver

Use the built-in PTZ drivers, including:

1. Custom Camera

2. Pelco D

3. Pelco P

Pelco D
