VPort ONVIF Profile S System Configuration

4-43

Step 1: Click the “Create New Trigger” button.

Step 2: Create the new trigger.

Setting Description Default

Trigger Name Configure the name of the new trigger None

Trigger event Select the event Type: Digital input, VMD, Tamper, CGI trigger,

Link status

Active Relay

Different triggers have different configuration items.

Digital input (not supported by all VPorts)

Settings Description Default

DI number

Select digital input

DI01

Logical State Configure the DI status to High or Low High

VMD

Settings Description Default

Channel Number Select the video source. Currently, VPort IP cameras only have

one video source.

videoSrccfg01

State Enable (true) or disable (false) the VMD trigger true

CGI trigger

Settings Description Default

CGItrigger Select from 5 CGI triggers. 1
