2
www.moxa.com
info@moxa.com
IP Surveillance
Dimensions
Unit: mm (inch)
60.92 (2.72)
90 (3.54)
90 (3.54)
216.1 (8.51)
1/4"-20UNC
1/4"-20UNC
1/4"-20UNC
1/4"-20UNC
Side Views Rear ViewFront View
Network
Protocols: TCP, UDP, HTTP, SMTP, FTP, Telnet, NTP, DNS, DHCP,
UPnP, RTP, RTSP, ICMP, IGMPv3, QoS, SNMPv1/v2c/v3, DDNS,
Modbus/TCP, 802.1X, SSL
Ethernet: 1 10/100BaseT(X) Ethernet port, RJ45 connector, or 1
100BaseFX, single mode
Serial Interface
RS-485: 1 full-duplex RS-485
GPIO
Digital Inputs: 1, max. 8 mA
• High: +13 to +30 V
• Low: -30 to +3 V
Relay Output: 1, max. 24 VDC @ 1 A
LED Indicators
STAT: Indicates if the system is booted properly or not
Network: 10 Mbps or 100 Mbps
Power: Power on/off
Local Storage
SD Socket: Standard SD socket (SDHC, SDXC)
Power Requirements
Input:
12/24 VDC, 24 VAC or Power-over-Ethernet (PoE+, 802.3at),
redundant power design
Power Consumption: 23 W
Physical Characteristics
Camera Body Housing: Metal, IP30 protection
Weight: 1415 g
Installation: Wall mounting, ceiling mounting, pole mounting, corner
mounting (optional external housing and mounting accessory may be
required)
Alarms
Video Motion Detection: 3 independently congurable motion areas
Camera Tamper: Sensitivity adjustable camera tamper detection
(Pending)
Scheduling: Daily repeat timing schedule
Imaging: JPEG snapshots for pre/trigger/post alarm images
Custom Alarms: HTTP event and CGI events for setting customized
alarm actions
Email/FTP Messaging: Automatic transfer of stored images via email
or FTP as event-triggered actions
Pre-alarm Buffer: 84 MB video buffer for JPEG snapshot images
Environmental Limits
Operating Temperature:
Standard Models: -25 to 60°C (-13 to 140°F)
Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Storage Temperature: -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Standards and Certifications
Safety: UL60950-1, EN 50121-4, NEMA TS2
EMI: FCC Part 15, CISPR (EN 55022) class A
EMS:
EN 61000-4-2 (ESD), Level 3,
EN 61000-4-3 (RS), Level 3,
EN 61000-4-4 (EFT), Level 3,
EN 61000-4-5 (Surge), Level 3,
EN 61000-4-6 (CS), Level 3,
EN 61000-4-8
Shock: IEC 60068-2-27
Freefall: IEC 60068-2-32
Vibration: IEC 60068-2-6
MTBF (mean time between failures)
Time: 169,886 hours
Database: Telcordia (Bellcore), GB 25°C
Warranty
Warranty Period: 3 years (not including moving parts; see Moxa’s
warranty policy online for details)
Details: See www.moxa.com/warranty
Software Development Kit
VPort SDK PLUS: Includes CGI commands, ActiveX Control, and API
library for customized applications or system integration for third-party
developers (latest version available on Moxa website).
Standard: ONVIF ProleS
