Moxa VPort 56-2MP-CAM10X-T [3/3] Ordering information

IP Surveillance

Available Models

VPort 56-2MP-CAM10X: Full HD zoom IP camera, RJ45 Ethernet port, 12/24 VDC or 24 VAC or PoE, -25 to 60°C

operating temperature

VPort 56-2MP-CAM10X-T: Full HD zoom IP camera, RJ45 Ethernet port, 12/24 VDC or 24 VAC or PoE, -40 to 75°C

operating temperature

VPort 56-2MP-CAM10X -S-SC: Full HD zoom IP camera, Single-mode ber Ethernet port, 12/24 VDC or 24 VAC, -25 to

60°C operating temperature

VPort 56-2MP-CAM10X-S-SC-T: Full HD zoom IP camera, Single-mode ber Ethernet port, 12/24 VDC or 24 VAC, -40 to 75°C operating temperature

Optional Accessories (can be purchased separately)

SoftNVR-IA: 64-channel IP surveillance software for industrial automation applications

DR-4524/75-24/120-24: 45/75/120 W DIN-Rail 24 VDC power supplies

MDR-40-24/60-24: 40/60 W DIN-Rail 24 VDC power supplies, -20 to 70°C operating temperature

Ordering Information

IP68 Indoor/Outdoor Housing

Protects camera for use in outdoor environments

VP-CI701

Construction: Die cast aluminum alloy

Dimensions: 406(L) x 109(H) x 145 (W) mm

View Window: Tempered glass

Housing Style: Clam Shell

Latch: Dual side screw-locking

Weight: 2,200 g

Wall Mount Bracket

For attaching the VP-CI701 housing to a wall

VP-CI800

Construction: Die cast aluminum alloy

Dimensions: 213 (L) x 146 (H) x 80(W) mm

Max Load: 20,000 g

Weight: 690 g

Pole Mount Bracket

For attaching the wallmount bracket to a pole

VP-CI815

Construction: Die cast aluminum alloy

Dimensions: 277.4 (L) x 75 (H) x 168.1 (W) mm

Max Load: 30,000 g

Weight: 2,400 g

Pole: Ø70 to Ø230 mm

Package Checklist

• VPort 56-2MP series

IP camera

• 9-pin terminal block

• 2-pin terminal block
