LED Indicators
The front panel of Moxa’s VPort 364A contains several LED indicators. The
function of each LED is described in the table below.
LED Color State Description
STAT Green/Red
Steady
Red
Hardware initialization stage.
Flashing
Red
Software initialization stage.
Steady
Green
System has booted up and is ready to
run.
Flashing
Green
Firmware is being upgraded.
PWR1 AMBER
On
Power is being supplied through power
input PWR1.
Off
Power is not being supplied through
power input PWR1.
PWR2 AMBER
On
Power is being supplied through power
input PWR2.
Off
Power is not being supplied through
power input PWR2.
FAULT RED
On
One of the following 3 conditions is
met:
One of the 2 power inputs is
disconnected.
Video loss.
Network disconnected.
Users can configure these alarm
settings on the system alarm page of
system configuration.
Off
Both power inputs are connected and
are working properly, there is no video
loss and the network is connected.
V1, V2,
V3, V4
GREEN
On
Video signal is detected
Off
Video signal is not detected
10/100
AMBER
On
10 Mbps link is active
Blinking
Data is being transmitted at 10
Mbps
Off
10 Mbps link is inactive
GREEN
On
100 Mbps link is active
Blinking
Data is being transmitted at 100
Mbps
Off
100 Mbps link is inactive
Hardware Reset
A recessed RESET button is provided for restoring the system to the
factory default settings. When the system fails to install properly, or
operates abnormally, use the RESET button located on the top panel of
the VPort 364A to restore the factory defaults.
To do this, use a pointed object such as a straightened paper clip or
toothpick, to depress the reset button continuously. Release the reset
button when the STAT LED stops flashing in red. At this point, the POST
