VPort 364A System Configuration
5-22
Setting Description Factory Default
Enable To enable or disable the DynaStream function. Disabled
Duration This refers to the time period that DynaStream is in operation
.
For example, if the duration is set to 5
seconds, then the frame
rate will change from the Live to the Alarm status for the
duration of 5 seconds. After 5 seconds, the frame rate will
return to the Live status setting.
5 seconds
Trigger Channel To enable or disable the video channels. Disabled
Video
